Lightning Protection Systems: ESE vs Conventional — What You Need to Know
Lightning Protection: Conventional vs ESE
Lightning strikes can cause devastating damage to buildings, equipment, and most importantly, endanger lives. Choosing the right lightning protection system is critical for any structure.
Conventional Lightning Protection
Based on Benjamin Franklin’s original concept, conventional (Franklin rod) lightning protection uses pointed conductors placed at the highest points of a structure.
How it works:Metal rods attract lightning strikesDown conductors carry the current to earthEarth termination system dissipates the energy
Protection Zone:Calculated using the rolling sphere methodTypically protects a cone-shaped areaMultiple rods needed for large structures
ESE Lightning Protection
Early Streamer Emission (ESE) technology uses an active device that triggers an upward streamer earlier than a conventional rod.
How it works:ESE device generates an early upward leaderCaptures the lightning strike before conventional rodsProvides a larger protection radius
Advantages:Wider protection area (up to 107m radius)Fewer devices needed per structureCertified to NF C 17-102Proven technology with decades of field experience
Comparison
|———|:—:|:—:|
Earth Termination
Both systems require an effective earth termination system:Minimum 2 earth electrodes per down conductorEarth resistance < 10 ohms (preferably < 1 ohm)Copper bonded or chemical earthing electrodes recommendedRegular testing required
Conclusion
Both conventional and ESE systems provide effective lightning protection when properly designed and installed. The choice depends on the structure’s size, complexity, and budget. Always consult a qualified lightning protection specialist.
